10w Connector Male 2,8
Sold as: A single part or part of a cable harness
Detail Product Description:
| Connector Gender: | Male |
| Numbers of Ways: | 10w |
| Pitch (mm): | 5 |
| Terminal Blade Size (mm): | 2.8 x 0.8 |
| Terminal No.: | Unsealed system male terminals acc. to TE C-1355364 |
| Cable Exit Angle: | 180° |
| Connector Size (L x W x H): | – |
| Connector Mounting Type: | – |
| Primary Product Color: | Black |
| Material: | PA6 GF30 |
| Operating Temperature Range: | TBD |
| Sealable: | Yes |
| Seal No.: | Sealing plate 42061400; Seal no. K4680960002 (around the connector) is part of the component |
| TPA – Terminal Positioning Assurance: | No |
| TPA no.: | – |
| Counterpart: | TE 1-967555-1; TE 1-967556-1 |
| Additional Accessories: | – |
| Sold as: | A single part or part of a cable harness |
Packaging Features:
| Packaging Type: | Cardboard box |
| Quantity (pcs): | 600 |
| Total Weight (Kg): | – |
| Size (L x W x H): | – |
